RY320 -2 color three-station printing machine
Product description
The reasonable and simple design structure, reliable quality, and affordable price of this 2-color flexographic printing machine guarantee its uniqueness. Can greatly save production time and cost. This machine is simple to operate, easy to use and other powerful functions, which is the most ideal for small and medium-sized enterprises, especially customers who have low printing requirements.
Features
1. Use ceramic anilox roller to transfer ink.
2. Each printing unit adopts 360°circumferential registration adjustment.
3. The computer correction device is located in front of the printing group. This design keeps the roll paper in the correct left and right positions during the entire production process. (Optional)
4. Unwinding and rewinding are controlled by magnetic powder automatic tension, and double rewinding can be added.
5. The ink roller can be detached automatically when parking, and run at low speed to prevent ink from drying out.
6. The main motor adopts imported frequency conversion stepless speed regulation.
7. It is the ideal model for printing commercial bills and high-end stickers for all kinds of printing plants, which can be completed at one time from tube feeding, printing, automatic infrared drying, and rewinding.
Technical parameter
|
Printing speed: |
50m-60m/min |
Voltage: |
380V±10% |
|
Printing colors: |
2 colors |
Total power: |
5kw |
|
Feeding width: |
320mm |
Total air pressure: |
0.6MP |
|
Maximum unwinding diameter: |
600mm |
Lubrication system: |
Artificial |
|
Maximum winding diameter: |
600mm |
weight: |
500kg |
|
Maximum printing size: |
175-370mm |
Dimensions: |
1200mmX1200mmX1400mm |
|
Overprint accuracy: |
±0.15mm |
|
|
The above technical parameters and pictures are for reference only, the actual product shall prevail
Successful printed matter case
