Small Flower Sleeve Making Machine
Product Description
This machine is special designed to make single small size flower packing sleeve.The machine adapt LED touch screen, imported silicon plate, double line folding and cutting device, make two lines non printed flower sleeves at one time,the speed is up to 300 pcs/min.The flower sleeve is well and strongly sealed at steady speed.
Machine Parameters
|
Model |
DRQ-E500 |
|
Material |
OPP, PE, PP |
|
Unwinding diameter |
Ф550mm |
|
Bag making width |
≤350mm |
|
Max Bag making length |
25-200mm |
|
Min Small up mouth width |
25mm |
|
Max down mouth width |
200mm |
|
Thickness |
0.015-0.08mm |
|
Max. speed |
30-120pcs/min (60-240pcs for non printed double lines) |
|
Voltage |
220V/1P/50hz |
|
Total power |
4KW |
|
Weight |
600KG |
|
Overall dimension |
4200×1600×1100mm |
