RLD Ribbon Through Continuous Rolled Bag Making Machine
Funcation
1.It's used for making garbage bag for daily life .with ribbon ,cutting off and rolled
2.rubbish bag
3.rolling refuse bag
1. This machine has been improved designed and manufactured by Our company referring to foreign technology(It is local to found).
2. It adopts computer control and stepper motor type.
3. It has such functions as photo electric automatic tracking, has blank bags and color bags change function. Microcomputer length setting, automatic counting, alarm on reaching the set value, control the temperature automatically.
4. It is such automatic mouth cutting-off and puching, half of park bore, ribbon-through belt, belt move, side and bottom sealing cutting off, right fold, continous-rolled and divide-rolled of machine install etc.
5. It adopts no tension sealing organization, seal and cutting-off synchronously, bottom film is beautiful.
6. It adopts process continuous-rolled ribbon-through type garbage, continous-rolled flat bags and flat bags function.
7. The whole machine adopts a product line, automatic high make, so it is a kind of ideal equipment for ribbon-through type garbage.
Product Description
RLD Series Ribbon Through Continuous Winding Bag Making Machine
Specification
|
Model No. |
RLD-800 |
RLD-1000 |
RLD-1300 |
|
Max. Width of bag-making |
800mm |
1000mm |
1300mm |
|
Max. Length of bag-making |
999mm |
999mm |
999mm |
|
Thickness of Film |
0.01-0.05mm |
0.01-0.05mm |
0.01-0.05mm |
|
Speed of bag making |
15-35pcs/min |
15-35pcs/min |
15-35pcs/min |
|
Total power |
5kw |
7.5w |
10kw |
|
Weight |
2200kg |
2800kg |
3200kg |
|
Machine Dimension |
8200×2600×2200mm |
8700×3100×2200mm |
9200×3100×2200mm |
