DZB T-Shirt And Flat Bag On Roll Bag Making Machine
Product Description
1.This machine is special for making unprinted or printed T-shirt bag or flat-open bag or garbage on roll.
2.This machine is equipped with computer to set the bag length and batch etc.to make the bag automaticlly,also the machine is with photocell, automatic material feeding device,automatic constant temperature control device, electrostatic removing device,automatic counting and alarm device etc.It's easy operation, stable performance and with high producing speed. This machine is the best machine to make T-shirt bag.
Specification
|
Model No. |
DZB-400 |
DZB-500 |
DZB-600 |
|
Max.Width of Sealing & Cutting |
400mm |
500mm |
600mm |
|
Length of Sealing & Cutting |
100-1000mm |
100-1000mm |
100-1000mm |
|
Speed of Bag-making |
40~120pcs/min |
40~120pcs/min |
40~120pcs/min |
|
Power of Main Motor |
1.1kw |
1.1kw |
1.5kw |
|
Weight of Machine |
800kg |
850kg |
900kg |
|
Dimension(mm) |
3300×1100×1500 |
3300×1200×1500 |
3300×1300×1500 |
|
Model No. |
DZA-800 |
DZA-1000 |
DZA-1100 |
|
Max.Width of Sealing & Cutting |
760mm |
960mm |
1100mm |
|
Length of Sealing & Cutting |
100-1000mm |
100-1000mm |
1100mm |
|
Speed of Bag-making |
40~120pcs/min |
40~120pcs/min |
22pcs/min |
|
Power of Main Motor |
1.5kw |
1.5kw |
3.0kw |
|
Weight of Machine |
1000kg |
850kg |
1100kg |
|
Dimension(mm) |
3300×1500×1500 |
3300×1700×1500 |
2600×1600×1400 |
Remark
We also have wider width machine,if you want to make special length and width bag,please feel free to contact us,we will provide you details.thanks.
